Pet Bottles Recycle Polyester Staple Fiber Recycling Machine Line

Overview

Basic Info.

Model NO.	XY-WPET500,XY-WPET1000,XY-WPET2000,XY-WPET3000,XY-
Computerized	Computerized
Certification	CE
Material of Crusher Blades	D2/SKD-11
Material of Washing Part	304 Stainlss Steel
Electric Control Panel	Siemens Brand
Colour of Machine	Customized
Final Product	Clean Pet Flakes (16-18mm, Customized)
Model	300/500/1000/2000/3000kg/Hr
Raw Material	Waste Pet Bottle
After-Sales Service Provided	Field Installation, Commissioning and Training
Transport Package	Composite Board Wooden Box or Plastic Film
Specification	depend on different models
Trademark	REGULUS
Origin	Jiangsu Province, China
HS Code	847780
Production Capacity	Depend on Different Models

Product Description

Product Description

Plastic PET bottles Recycling Line

1. PET bottle recycling washing line is mainly used for crushing, washing plastic bottles, plastic barrels, coca cola bottles,
mineral water bottles into PET flakes.
2. The whole production line reasonably structured, high degree automation, low electric energy consumption, high capacity, good clean effect, long using life.
3. Final product PET flakes can be used for chemical fiber factory after this line, and used for producing PET strap, no need to do any treatment.
4. Product capacity range is 500-6000 kg/hr
5. Size of final product can be adjusted according to change crusher screen mesh.

Complete recycling process

Working Flow:

Belt conveyor → Bale opener machine → Belt conveyor → Pre-washer (trommel) →Belt conveyor → Mechanical label remover → Manualseparating table → Metal detector →Belt conveyor → Crusher → Screw conveyor → Floating washer →Screw conveyor → Hot washer chamber →Screw conveyor*2 → High speed friction machine → Screw conveyor → Floating washer → Screw conveyor →Floating washer→Screw conveyor → Horizontal dewatering machine → Drying pipe system → Zig zag air classification system → Storage hopper → Control cabinet

Product Parameters

Model	Capacity(kg/h)	Install Power	Water Supply(m3/h)	Manpower	Humidity Content
XY-PET500	500	220	1	5	<0.8%
XY-PET1000	1000	500	3	6	<0.8%
XY-PET2000	2000	700	5	8	<0.8%
XY-PET3000	3000	900	6	10	<0.8%
XY-PET4500	4500	1000	8	12	<0.8%
XY-PET6000	6000	1200	10	16	<0.8%

Company ProfileFunction: Break the compressed bottle bales into loose bottles, easy for the following recycling processDebale machine/Blaes opener
Function: Remove the bottles labels and part of caps, pre-washing bottles. The caps of PET bottles are usually made of PP and PE materials, caps are poorly compatible with PET, which will cause the performance of the machine to decrease during granulation. Labels are usually made of PVC, which has poor thermal stability and will decompose when heated. labels will affect the quality of the final PET particles. Bottle label removing machine
Function: Removal many of the solid contaminants (sand, stones, etc.), and represents the first dry cleaning step of the process. Dry separation/ Trommel:
Sorting conveyor with metal detector
Function: Select and sort different kinds color plastic bottles, remove metal Crusher
Function: Cut material into flakes, easy for washing and drying.Feature:1. rotor with balance treatment for stability and low noise 2. rotor with heat treatment for long lifespan 3. wet crushing with water, which can cool the blades and wash the plastic in advance 5. special rotor structure design for different plastics like bottles or film 6. blades made of special material, with high hardness 7. easy operation to change blades or screen mesh 8. high capacity with stability
Floating washer:
Function: Washing and cleaning PET flakesFeatures:1. rinse the pieces of flakes or scraps in water 2, can use hot type washer to add chemical for washing 3. upper roller be inverter controlled 4. all washer tank made of 304 stainless steel or even 316 stainless steel if needed 5. bottom screw can process sludge Hot washer Tank
Material: all washer tank made of 304 stainless steel or even 316 stainless steel if needed
Function: Clean PET flakes by hot water and chemical.After hot washing, it's easier to remove oil, glue. Structure:Outer layer: Carbon steel Inner layer: stainless steel Middle layer: rock wool for insulation Caustic soda percentage:1-2% Temperature of hot water:70-90 centigrade Working method:Non-stop flakes feeding and loading out. Friction washer
Function: Friction to clean the materials mechanically Feature:1. rotor made of strong & thick material, surface treatment with alloy 2. rotor with balance treatment for stability 3. rotor with heat treatment for long lifespan 4. The bearing is externally connected with water cooling sleeve, which can effectively cool the bearing. Dewatering machine
Function:Drying materials by centrifugal force Feature:1. rotor made of strong&thick material, surface treatment with alloy 2. rotor with balancetreatment for stability 3. rotor with heat treatment for long lifespan 4. The bearing is externally connected with water cooling sleeve, which can effectively cool the bearing. Label separate & Dust remover
Material:Stainless steel
Function: remove the light impurity as dust and label in dried bottle flakes.
FAQ

Q: How to contact you if I am interested with your machine?
A: You can contact us via Alibaba, we will reply you ASAP. Q: How to choose model of your machine?
A: You could send us your raw material pictures, and tell us how many tons plastic you plan to recycle in one month, and how many working hours in one month. Then we will recommend you the suitable machine
Q: If I need the machine urgently, can you send to me on time?
A: We have enough storage in our warehouse, and the storage ranges from the main machines to the small spares. we can assemble and test the machine in a very short time and send to you by the fastest speed
Q: China industrial power supply is 3 phase, 380 V, 50 Hz, can your company custom-made different electric voltage?
A: Yes, besides 3 phase, 380 V, 50 hz machine, we can custom-made different electric voltage according to different country clients requirement. Such as 3 phase, 220 V, 60 Hz, 240 V, 415 V, 440 V, 480 V
Q: How can I believe your factory and machines.A: We have CE, ISO certificates. And we have customers all around the world.1.After finishing the production, we will debug the production line, take photos, videos and send them to customers via mail or instant tools.2.After the commissioning, we will package the equipment by the standard export package for shipment.3.According to the customer's request, we can arrange our engineers to customers' factories to do the installation and training.4.Engineers, sales managers, and after-sales service managers will form an after-sales team, online and offline, to follow the customers' project.
